What is BTS7960B Chip?

 The BTS7960B is a high-current, high-voltage power MOSFET driver designed for automotive and industrial applications, specifically tailored for motor control. It is part of the BTS family from Infineon Technologies and is widely used in applications requiring efficient switching and control of DC motors.

Key Features:

  1. High-Current Capability: The BTS7960B can handle continuous currents of up to 43A, making it suitable for driving high-power motors in various applications.

  2. Wide Voltage Range: It operates over a supply voltage range of 5.5V to 40V, allowing it to accommodate a variety of system requirements.

  3. Integrated Protection Features: The device includes built-in protections such as over-temperature protection, over-voltage protection, and short-circuit protection, ensuring safe operation under various conditions.

  4. H-Bridge Configuration: The BTS7960B is designed for H-Bridge applications, enabling bidirectional control of DC motors with high efficiency.

  5. Low On-Resistance: The IC features a low on-resistance (typically around 10 mΩ), which minimizes power losses during operation and enhances overall efficiency.

Applications:

  • DC Motor Control: Commonly used in applications such as robotics, automotive power windows, and seat adjustments where precise motor control is required.
  • Actuator Control: Suitable for controlling actuators in various industrial and automotive systems.
  • Power Steering Systems: Often implemented in electronic power steering systems for efficient motor control.
  • Industrial Automation: Used in various automation applications requiring robust and reliable motor driving capabilities.

Technical Specifications:

  • Operating Voltage: 5.5V to 40V.
  • Continuous Current: Up to 43A.
  • On-Resistance: Typically around 10 mΩ.
  • Package Type: Available in a DPAK package, allowing for easy integration into designs.

The BTS7960B is well-regarded for its robustness, efficiency, and integrated safety features, making it a preferred choice among engineers and designers for motor control applications in automotive and industrial environments. Its ability to handle high currents while providing reliable protection mechanisms enhances its appeal in demanding applications.
